LCD Monitor|DAHUA|LM22-A200Y|21.45″|Panel VA|1920×1080|16:9|100Hz|10 ms|DHI-LM22-A200Y
64,57 € (bez PVN: 53,36 €)
Noliktavā: 30
Pieejams veikalā: 26/05/2026
Garantija: 12/24 mēn.
21.45 ” | 1920 x 1080 pixels | Full HD | 16:9 | LED | VA | 10 ms | Flat | Contrast 3000:1 | Maximum refresh rate 100 Hz | 1xHDMI ports quantity | VESA Yes
| Data Sheet (Link) |
https://eprel.ec.europa.eu/api/product/2139333/fiches?language=EN |
|---|---|
| Energy efficiency class |
E |
| EPREL Registration Number |
2139333 |
| EPREL Version Number |
1 |
| Unit Calculated Weight |
3.06 kg |
| Product Net Weight |
2.05 kg |
| Unit Calculated Volume |
0.0222 cubm |
| Units per Pallet |
0 |
| Compliance certificates |
CE/Electromagnetic Compatibility (EMC)/Low Voltage Directive (LVD) |
| Vendor Homepage |
https://www.dahuasecurity.com/search/products?keyword=DHI-LM22-A200Y |
| Category Code |
LC3 |
| Unit Box Height |
0.37 |
| Unit Box Length |
0.6 |
| Unit Box Width |
0.1 |
| Power adapter included |
Yes |
| Stand included |
Yes |
| Package depth |
99 mm |
| Package height |
366 mm |
| Package type |
Box |
| Package weight |
2860 g |
| Package width |
598 mm |
| Bezel width (bottom) |
15.2 mm |
| Bezel width (side) |
3.3 mm |
| Bezel width (top) |
3.3 mm |
| Depth (without stand) |
41.2 mm |
| Height (without stand) |
284 mm |
| Weight (without stand) |
2050 g |
| Width (without stand) |
492.7 mm |
| Operating temperature (T-T) |
0 – 40 °C |
| Storage temperature (T-T) |
-20 – 60 °C |
| AC adapter output voltage |
12 V |
| Current rating |
2 A |
| Energy efficiency class (HDR) |
Not available |
| Energy efficiency class (SDR) |
E |
| Energy efficiency scale |
A to G |
| Power consumption (max) |
16 W |
| Power consumption (off) |
0.1 W |
| Power consumption (standby) |
0.1 W |
| Power consumption (typical) |
16 W |
| Power supply type |
External |
| Height adjustment |
No |
| Panel mounting interface |
75 x 75 mm |
| Plug and Play |
Yes |
| Tilt adjustment |
Yes |
| Tilt angle range |
-5 – 15 ° |
| VESA mounting |
Yes |
| Wall mountable |
Yes |
| Built-in USB hub |
No |
| HDMI |
Yes |
| HDMI ports quantity |
1 |
| HDMI version |
1.4 |
| Headphone out |
No |
| VGA (D-Sub) ports quantity |
1 |
| Detachable stand |
Yes |
| Feet colour |
Black |
| Frameless design |
Yes |
| Front bezel colour |
Black |
| Product colour |
Black |
| Built-in camera |
No |
| Built-in speaker(s) |
No |
| Backlight type |
Edge LED |
| Colour depth |
8 bit |
| Colour gamut standard |
NTSC |
| Contrast ratio (typical) |
3000:1 |
| Display brightness (typical) |
250 cd/m² |
| Display diagonal |
21.45 " |
| Display diagonal (metric) |
56 cm |
| Display resolution |
1920 x 1080 pixels |
| Display technology |
LED |
| HD type |
Full HD |
| LED backlight |
Yes |
| Maximum refresh rate |
100 Hz |
| Native aspect ratio |
16:9 |
| NTSC coverage (typical) |
72 % |
| Panel type |
VA |
| Response time |
10 ms |
| Screen shape |
Flat |
| Touchscreen |
No |
| Viewing angle, horizontal |
178 ° |
| Viewing angle, vertical |
178 ° |
| Model name |
LM22-A200Y |
| Model |
DHI-LM22-A200Y |
